DRL-48V240W1EN

Available: All prices Exclude VAT. Shipping and Vat will be calculated at checkout

Wishlist Compare

NOTE: If Product Price Is R0.00 - Contact Us For A Quote DRL-48V240W1EN

R 1,535.49

Description

**Industrial Power Supply Unit

48V, 240W

OUTPUT
DC VOLTAGE48V DC
CONSTANT CURRENT REGIONNote.243.2-52.8V DC
RATED CURRENT(ForBETypeonly)5A
RATED POWER240W
RIPPLE & NOISE (Max.) Note.3
< 200mVpp @ 0°C to +70°C

< 600mVpp @ -30°C to 0°C
VOLTAGE TOLERANCE Note.4±1.0%
HOLD UP TIME (Typ.)
20ms typ. @ 115Vac (100% load)

20ms typ. @ 230Vac (100% load)

ENVIRONMENT
WORKING HUMIDITY5 to 95% RH (Non-Condensing
STORAGE TEMP., HUMIDITY40°C to +85°C

SAFETY& EMC
SAFETY STANDARDS
IEC 62368-1, IEC 60950-1, IEC 61010-1 & -2-201

EN 62368-1, EN 61010-1 & -2-201

UL 62368-1

GB4943.1

TP TC 004/2011

K60950-1 (24V model only)

In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU

OTHERS
DIMENSION123.6 x 40 x 117.2 mm (4.87 x 1.57 x 4.61 inch)
PACKING0.62 kg (1.37 lb)

**Industrial Power Supply Unit

48V, 240W

OUTPUT
DC VOLTAGE48V DC
CONSTANT CURRENT REGIONNote.243.2-52.8V DC
RATED CURRENT(ForBETypeonly)5A
RATED POWER240W
RIPPLE & NOISE (Max.) Note.3
< 200mVpp @ 0°C to +70°C

< 600mVpp @ -30°C to 0°C
VOLTAGE TOLERANCE Note.4±1.0%
HOLD UP TIME (Typ.)
20ms typ. @ 115Vac (100% load)

20ms typ. @ 230Vac (100% load)

ENVIRONMENT
WORKING HUMIDITY5 to 95% RH (Non-Condensing
STORAGE TEMP., HUMIDITY40°C to +85°C

SAFETY& EMC
SAFETY STANDARDS
IEC 62368-1, IEC 60950-1, IEC 61010-1 & -2-201

EN 62368-1, EN 61010-1 & -2-201

UL 62368-1

GB4943.1

TP TC 004/2011

K60950-1 (24V model only)

In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU

OTHERS
DIMENSION123.6 x 40 x 117.2 mm (4.87 x 1.57 x 4.61 inch)
PACKING0.62 kg (1.37 lb)
