AE-DC5013-F6 Pro_C
**1600P Dashcam
- Up to 1600P high resolution, gold wide angle up to 130°.
- F1.6 super large aperture offering a perfect night image.
- Support built-in MIC and speaker for audio in and out.
- Built-in WIFI module and WIFI AP function supported.
- Built-in G-Sensor module, support video recording linkage at car crash or strong vibration. (Linkage video record can be configured be no-overwritten)
- Micro SD card for video recording, up to 256GB. (Overwriting supported)
- Phone App: live view, record playback and parameter configuration.
- Voice recognition supported : Snapshot, Recording on, Recording off.
- ADAS supported: “Traffic light turn green”, “Speed limit recognition”, “Front car start remind”.
- Easy installation and user friendly, plug and play. (Automatically recording after power on)
- Low power consumption and high performance.
Specification
- Camera
- Image SensorOV-05A20
- Angle AdjustmentAjustable up angles 30°
- Power-Off MemoryYES
- Lens
- Lens TypeG+P
- ApertureF1.6
- Wi-Fi
- Frequency Range2412-2472MHZ
- Channel Bandwidth20MHZ/40MHZ
- Image
- Wide Dynamic Range (WDR)NO
- Image EnhancementYES
- Interface
- Built-In MicrophoneYES
- Built-In SpeakerYES
- General
- GPSNO
- WiFi2.4G
- Wi-Fi SupportYES
-
Resolution
1600p@30fps, 1600p@25fps;
1440p@30fps, 1440p@25fps;
1080p@30fps, 1080p@25fps
- Max. Resolution1600p@30fps
- Video CompressionH.265
- FOV130° (D), 109° (H)
-
Camera Dimension
52mm x 50.4mm x 51.9mm
(2.04 x 1.98\" x 2.04\")"
- Camera Weight120 g (0.26 lb)
- Software ResetYES
- Online UpgradeYES
- Power Consumption And Current3.5W
- Power Supply5V DC, 2 A
- Power InterfaceMicro
- Working Temperature-20 °C to 70 °C (-4 °F to 158 °F)
- Working Humidity95%(Max)
- StorageTF card, Max. 128 GB
- OSDDisplay time, date, etc.
- Image FormatJPEG
- Local StorageNO
- ADASYES
- Speech RecognitionYES
